1T 16Mn 50mm Trailer Drop Axles Boats Cars 2000 Lb Drop Axle

Name: 1T 16Mn 50mm Trailer Drop Axles Boats Cars 2000 Lb Drop Axle
Brand: Airui
Price: 1 USD

Buy cheap 1T 16Mn 50mm Trailer Drop Axles Boats Cars 2000 Lb Drop Axle product

Brand Name : Airui

Model Number : AC015

Certification : ISO/TS16949

Place of Origin : Shandong，China

MOQ : Deliberations

Price : Deliberations

Payment Terms : L/C, T/T

Supply Ability : 5000 Piece/Pieces per Month

Delivery Time : 5-8 work days

Packaging Details : 1. Iron frame packing. 2. As your requirements

Use : Trailer Axle Use

Size : 50mm ,free length, Optional

Material : 16 Mn

oil seal : I.D.43.5 mm single lip

Max Payload : 1t

Surface treatment : Painted Etc

Brake : Unbrake axle

length : Customer Model

Contact Now

2500-3500 Kg Lbs 50mm Free Length Square Unbraked Drop Axle For Boats Cars Trailer

Axle with brake, long axle section available in hollow round tube, hollow square tube, or solid round steel, solid square steel.

With our clear axle product differentiation, we offer the optimal solution for each purpose: This also enables you to clearly differentiate your products with optimal value creation.

Double radial angled ball bearing (compact bearing)

I Dimensioned for a bearing lifeof up to 250,000 km.

I Maintenance-free.

I Lifetime lubrication with special grease containing water-repellent additives.

I Protected against dirt and water.

I A dust plate on the outside(double seal) prevents dirtingress.

I Easy to install due to standardised tightening torque.

I A watertight compact bearing is available specifically for boat trailers.

5* 4.5", 6*5.5" wheel bolts pattern
NO.	Description	QTY	option 1	option 2	option 3
1	axle shaft	1	45mm Rd / Sq solid	50mm Rd / Sq solid	60*5mm round tube
2	mounting plate	2	AT01200107
3	10" brake plate	2	AZ013L/R	AZ004L/R	AZ026L/R
4	bolt	8	AC00100501
5	washer & nut	8	AC00100502/3
6	oil seal	2	AC00500201
7	inner bearing	2	L68149/10
8	10" hub drum	2	AC00500300
9	wheel nut	8,10,12	1/2"-10UNF	7/16"-20UNF
10	outer bearing	2	LM12749/10	L68149/10
11	flat washer	2	AC00500402
12	castle nut	2	AC00500403
13	split pin	2	AC00500404
14	dust cap	2	AC00500405

1T 16Mn 50mm Trailer Drop Axles Boats Cars 2000 Lb Drop Axle

FAQ

Q1, What is your package types?
A: Generally, in neutral white boxes and brown cartons or as ur requirements.

Q2, What is your terms of payment?
A: 30% T/T in advance and 70% before shipping or against by BL copy.
Q3, What is your payment terms?
A: EXW,FOB, CNF & CIF.
Q4, How about your delivery time?
A: Usually,within 30-60 days after receiving the deposit or depending on the order’s requirements.
Q5, Can you produce according to the samples?
A: Yes,we can produce by your samples or technical drawing.
Q6, What is your sample price?
A: Sample design is free, sample and the express cost without free.
Q7, Do you test all your product before delivery?
A: Yes,we have 100% test before delivery.
Q8: How to establish the long-term stable business relationship with your company?
A: We can supply good and competitive price cargo to make sure the win-win relationship.
